Model 1000
RTU (Remote Terminal Unit)
The Model 1000 RTU offers the latest in flexible, intelligent monitoring for contact points (12), an analog input, comprehensive IP management, and access capabilities to sites. The Model 1000 furnishes the capability to cost-effectively manage your remote sites with multiple serial and Ethernet ports. It also has the capability to function as a sub-net (managed switch), eliminating the additional cost of connectivity for other equipment at remote sites.Â
The Model 1000’s ability to provide site alarm monitoring and I/O capacity to passive equipment makes it an intelligent extension of the Cordell C5 Network Management System®. The Cordell RTU family is designed to enhance your network management strategy, reduce costs, and improve operational efficiency. Â
While doing so, the Model 1000 provides a small footprint. Input and output connections conveniently located on the front panel ensure a simple and efficient installation process. All connectors are removable for easy maintenance. The Model 1000 is powered by a DC input (24vDC or 48vDC), and there is a direct battery backup connection (24vDC) available.Â

Features:
- 12 inputsÂ
- One control outputÂ
- Monitor input to 60vDCÂ
- Two Ethernet portsÂ
- Two async portsÂ
- Analog inputÂ
- 24 volt battery backupÂ
- Stores data up to seven days or last 100 alarmsÂ
- Wall or cabinet mountingÂ
- SNMP versions 2 and 3Â
Specifications:
- Web-based user interface or command line interfaceÂ
- SNMP MIPÂ
- SMSÂ
- DC powered Â
- SSHv2/HTTPS/SFTPÂ
- Console port for local access
